CGNAT (Carrier-Grade NAT): The Definitive, Example-Driven Guide for Sysadmins & Network Engineers

Introduction

Carrier-Grade NAT (CGNAT) is one of those technologies that quietly rewrote how the internet works, without most users realizing it.

For sysadmins and network engineers, CGNAT is often discovered only after something breaks:

• A VPN that won’t connect
• A game showing “Strict NAT”
• A server banning hundreds of innocent users
• Logs that suddenly stop making sense

This guide explains CGNAT from first principles, with real-world examples, packet-level reasoning, and design implications so you can reason about it correctly instead of guessing.

What Exactly Is CGNAT?

CGNAT (Carrier-Grade Network Address Translation) is a large-scale NAT system operated by ISPs that allows many subscribers to share a limited pool of public IPv4 addresses.

Unlike home NAT:

• You do not control it
• You cannot configure it
• You cannot port-forward through it
• You share identity with strangers

Simple Definition

CGNAT is NAT performed inside the ISP network, after your own router has already performed NAT.

Why CGNAT Became Inevitable (With Numbers)

IPv4 Reality Check

• Total IPv4 addresses: ~4.3 billion
• Usable after reservations: far less
• Devices online today: tens of billions

ISP Math Example

Assume:

• ISP has 1 million customers
• ISP owns 50,000 public IPv4 addresses

Without CGNAT:

• 950,000 customers get nothing

With CGNAT:

• Each public IP is shared by ~20 users (or more)

CGNAT is not optional — it is survival math.

How CGNAT Works (Concrete Packet Example)

Step-by-Step Example: Opening a Website

User Device

Laptop IP: 192.168.1.10

Home Router NAT

192.168.1.10:51543 → 100.72.14.22:40001

ISP CGNAT Gateway

100.72.14.22:40001 → 203.0.113.45:62011

Website Sees

Client IP: 203.0.113.45
Client Port: 62011

Now imagine 2,000 users doing the same thing through that same public IP.

CGNAT Address Range (RFC 6598 – Explained Properly)

Reserved Range

100.64.0.0/10

Expanded:

100.64.0.0 – 100.127.255.255

Why This Range Exists

Before RFC 6598:

• ISPs abused private IPs internally
• Overlapping private ranges caused routing nightmares
• Customer VPNs broke constantly

RFC 6598 created a dedicated ISP-only gray zone.

Is CGNAT Public or Private? (With Real Meaning)

This is where many engineers get it wrong.

Classification Table

Practical Meaning

• You cannot reach a CGNAT IP from the internet
• You cannot trust it for identity
• It exists only inside ISP infrastructure

Real-World Detection Example

Scenario: “Why is port forwarding not working?”

You log into your router and see:

WAN IP: 100.75.221.18

You check an external site:

Public IP: 203.0.113.45

Conclusion:

You are behind CGNAT.
Port forwarding will never work, no matter how perfect your config is.

Port Allocation: The Hidden Constraint

Why Ports Matter

Each IPv4 address has:

65,535 TCP/UDP ports

If 2,000 users share one IP:

65,535 ÷ 2,000 ≈ 32 ports per user

ISPs therefore:

• Allocate port blocks dynamically
• Reclaim aggressively
• Enforce session limits

Example: Port Exhaustion Failure

Scenario: Heavy Torrent + Browser + VPN

User opens:

• Torrent client (hundreds of connections)
• Browser tabs
• Video streaming

Result:

• Ports exhausted at CGNAT
• New connections fail
• Websites randomly stop loading

User thinks:

“Internet is unstable”

Reality:

CGNAT session limit hit

CGNAT vs Traditional NAT (Deep Comparison)

Legal & Forensic Implications (Very Important)

Example: Abuse Complaint

A website logs:

203.0.113.45 at 14:03 UTC

ISP must identify:

• Which subscriber
• Which port
• At exact timestamp

Without port-level logs, attribution is impossible.

This is why CGNAT logging systems are:

• Massive
• Expensive
• Retention-heavy

CGNAT and IP Reputation (False Guilt Example)

Scenario

One user behind CGNAT:

• Spams
• Scans
• Attacks

Result:

• Public IP gets blacklisted
• 500 innocent users blocked

This is why IP-based bans are obsolete in 2026.

VPNs and CGNAT (Why Inbound Breaks)

Inbound VPN (Fails)

Internet → CGNAT → ??? → You

No static mapping = no connection.

Outbound VPN (Works)

You → VPN Server → Internet

This is why:

• WireGuard
• Tailscale
• ZeroTier
• Reverse SSH tunnels

work well behind CGNAT.

Gaming Example: “Strict NAT”

Games require:

• Peer discovery
• Incoming packets

Behind CGNAT:

• No inbound mapping
• NAT traversal fails

Result:

• Strict NAT
• Limited matchmaking
• High latency relays

Hosting Services Behind CGNAT (Why It’s Impossible)

Attempting to Host a Web Server

You configure:

Port 80 → Internal IP

But:

• ISP NAT has no idea who you are
• No persistent mapping exists

Only solutions:

• Buy static public IPv4
• Use IPv6
• Reverse proxy via cloud
• Tunnel traffic outward

CGNAT + IPv6 (How ISPs Really Deploy It)

Most modern ISPs use:

IPv6 (native, public)
IPv4 (CGNAT fallback)

Example

• Website supports IPv6 → direct connection
• IPv4-only site → CGNAT

This hybrid model reduces:

• NAT load
• Logging pressure
• IPv4 dependency

CGNAT in Cloud Platforms (Hidden but Real)

AWS NAT Gateway Example

• Thousands of EC2 instances
• Limited public IPs
• Port-based translation

Same problems:

• SNAT exhaustion
• Per-destination limits
• Logging requirements

CGNAT is not just an ISP problem.

Design Rules for Sysadmins & Architects

Rule 1: Never Trust IPs Alone

Use:

• Auth tokens
• Certificates
• Application identity

Rule 2: Log Ports

IP without port is meaningless.

Rule 3: Assume NAT Everywhere

Even “public cloud” uses NAT internally.

Rule 4: Prefer IPv6

End-to-end connectivity is restored.

Quick CGNAT Troubleshooting Checklist

• WAN IP in 100.64.0.0/10?
• Public IP mismatch?
• Port forwarding ignored?
• Random connection drops?
• Shared IP reputation issues?

If yes → CGNAT.

Final Thoughts

CGNAT is:

• A technical compromise
• A legal headache
• A debugging nightmare
• A necessary evil

But for sysadmins and network engineers, it must be understood, not cursed.

Those who understand CGNAT:

• Debug faster
• Design smarter
• Avoid false conclusions
• Build future-proof systems

CGNAT is not the future.
IPv6 is.

But until then, CGNAT is the battlefield you are already standing on.
